ARC DUALLY

Be the first to review this product

ARC DUALLY

Be the first to review this product

This product is fitment specific

To see if this product is compatible Select a vehicle

Qty

Starting at $460.00

You have not specified your vehicle; therefore, we cannot guarantee this product will fit. To guarantee fitment, please select your vehicle.

Description

The Fuel Off-Road Arc Dually series elevates the rugged functionality of the Arc line to meet the specific needs of dual-rear-wheel trucks. Featuring a convex front wheel and deep concave rear wheel, this series emphasizes heavy-duty load capacity. The Arc Dually is designed to handle the heavier payloads and towing demands typical of dual-rear-wheel trucks like the Chevy Silverado 3500HD, GMC Sierra 3500HD, RAM 3500, and Ford F-350 Super Duty. Available in a 20" diameter, it offers tailored options for dually configurations.

Select all options to view Specs

Locate Your Nearest Installer Covered By Wheel Pros Limited Warranty

To the fullest extent recognized by the laws of the state where the wheel was purchased, Fuel Off-Road issues this limited warranty to define the rights of the purchaser, and limit Fuel Off-Road liability, with regard to warranty claims.

Fuel Off-Road warrants that our wheels will be free from structural failure under normal and intended use for as long as the original retail purchaser owns the product. Customers are specifically directed to the Fuel Off-Road Consumer Information and WTC Aftermarket Wheel Installation Guidelines, supplied with the wheel. Failure to comply with these instructions shall void this warranty.

See full Warranty details.

Fitment Guide

Specifications Chart

20"

22"

Part#	Model	Finish	Size	Bolt Pattern	Backspace	Offset	Bore	Weight	Load	Lip Size	Cap	MSRP USD
D8672082A9	D867 ARC DUALLY	BLACKOUT	20X8.25	10X225	8.72	104mm	170.10	45.90 lbs	3750	1.11	1004-62BLD	$655.00
D8672082A935	D867 ARC DUALLY	BLACKOUT	20X8.25	10X225	-3.29	-201mm	170.10	45.18 lbs	3750	7.36	1004-63BLD	$655.00
D86720827235	D867 ARC DUALLY	BLACKOUT	20X8.25	8X165.1	-4.31	-227mm	117.00	53.80 lbs	3000	7.36	1005-28BLD	$655.00
D86720828D	D867 ARC DUALLY	BLACKOUT	20X8.25	8X165.1	8.72	104mm	121.50	44.10 lbs	3000	1.11	1005-27BLD	$460.00
D86720827225	D867 ARC DUALLY	BLACKOUT	20X8.25	8X165.1	-3.29	-201mm	117.00	48.95 lbs	3000	7.36	1005-28BLD	$655.00
D86720828D35	D867 ARC DUALLY	BLACKOUT	20X8.25	8X165.1	-4.82	-240mm	121.50	51.48 lbs	3000	7.88	1005-28BLD	$460.00
D867208272	D867 ARC DUALLY	BLACKOUT	20X8.25	8X165.1	8.72	104mm	117.00	44.30 lbs	3000	1.11	1005-27BLD	$655.00
D86720829245	D867 ARC DUALLY	BLACKOUT	20X8.25	8X200	-4.31	-227mm	142.00	51.82 lbs	3000	7.36	1005-30BLD	$460.00
D867208292	D867 ARC DUALLY	BLACKOUT	20X8.25	8X200	8.72	104mm	142.00	43.20 lbs	3000	1.11	1005-29BLD	$460.00
D86720829235	D867 ARC DUALLY	BLACKOUT	20X8.25	8X200	-3.29	-201mm	142.00	47.63 lbs	3000	7.36	1005-30BLD	$460.00
D86720829335	D867 ARC DUALLY	BLACKOUT	20X8.25	8X210	-4.31	-227mm	154.30	50.49 lbs	3000	7.36	1005-30BLD	$460.00
D867208293	D867 ARC DUALLY	BLACKOUT	20X8.25	8X210	8.72	104mm	154.30	42.80 lbs	3000	1.11	1005-29BLD	$460.00
D86720829345	D867 ARC DUALLY	BLACKOUT	20X8.25	8X210	-5.06	-246mm	154.30	49.94 lbs	3000	7.88	1005-30BLD	$655.00
D86720829325	D867 ARC DUALLY	BLACKOUT	20X8.25	8X210	-3.29	-201mm	154.30	46.97 lbs	3000	7.36	1005-30BLD	$460.00
D8682082A935	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	10X225	-3.29	-201mm	170.10	45.18 lbs	3750	7.36	1004-63GB	$679.00
D8682082A9	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	10X225	8.72	104mm	170.10	45.90 lbs	3750	1.11	1004-62GB	$679.00
D86820827245	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X165.1	-5.06	-246mm	117.00	52.58 lbs	3000	7.88	1005-28GB	$679.00
D86820827235	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X165.1	-4.31	-227mm	117.00	53.80 lbs	3000	7.36	1005-28GB	$579.00
D86820828D	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X165.1	8.72	104mm	121.50	44.10 lbs	3000	1.11	1005-27GB	$679.00
D86820827225	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X165.1	-3.29	-201mm	117.00	48.95 lbs	3000	7.36	1005-28GB	$579.00
D86820828D35	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X165.1	-4.82	-240mm	121.50	51.48 lbs	3000	7.88	1005-28GB	$579.00
D868208292	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X200	8.72	104mm	142.00	43.20 lbs	3000	1.11	1005-29GB	$579.00
D86820829245	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X200	-4.31	-227mm	142.00	51.82 lbs	3000	7.36	1005-30GB	$579.00
D86820829235	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X200	-3.29	-201mm	142.00	47.63 lbs	3000	7.36	1005-30GB	$579.00
D868208293	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X210	8.72	104mm	154.30	42.80 lbs	3000	1.11	1005-29GB	$579.00
D86820829335	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X210	-4.31	-227mm	154.30	50.49 lbs	3000	7.36	1005-30GB	$579.00
D86820829325	D868 ARC DUALLY	GLOSS BLACK MILLED	20X8.25	8X210	-3.29	-201mm	154.30	46.97 lbs	3000	7.36	1005-30GB	$579.00
D8912082A9	D891 ARC DUALLY	POLISHED	20X8.25	10X225	8.72	104mm	170.10	45.90 lbs	3750	0.95	1004-62	$775.00
D8912082A935	D891 ARC DUALLY	POLISHED	20X8.25	10X225	-3.29	-201mm	170.10	45.18 lbs	3750	7.36	1004-63	$775.00
D89120827225	D891 ARC DUALLY	POLISHED	20X8.25	8X165.1	-3.29	-201mm	117.00	48.95 lbs	3000	7.36	1005-28	$725.00
D89120828D	D891 ARC DUALLY	POLISHED	20X8.25	8X165.1	8.72	104mm	121.50	44.10 lbs	3000	0.95	1005-27	$725.00
D89120828D45	D891 ARC DUALLY	POLISHED	20X8.25	8X165.1	-5.81	-265mm	121.50	55.30 lbs	3000	7.88	1005-28	$725.00
D89120828D35	D891 ARC DUALLY	POLISHED	20X8.25	8X165.1	-4.82	-240mm	121.50	50.90 lbs	3000	7.88	1005-28	$725.00
D89120827235	D891 ARC DUALLY	POLISHED	20X8.25	8X165.1	-4.31	-227mm	117.00	53.80 lbs	3000	7.36	1005-28	$725.00
D89120827245	D891 ARC DUALLY	POLISHED	20X8.25	8X165.1	-5.06	-246mm	117.00	52.00 lbs	3000	7.88	1005-28	$725.00
D89120821745	D891 ARC DUALLY	POLISHED	20X8.25	8X170	-4.31	-227mm	125.10	53.14 lbs	3000	7.36	1005-28	$725.00
D89120821735	D891 ARC DUALLY	POLISHED	20X8.25	8X170	-3.29	-201mm	125.10	48.51 lbs	3000	7.36	1005-28	$725.00
D891208217	D891 ARC DUALLY	POLISHED	20X8.25	8X170	8.72	104mm	125.10	43.90 lbs	3000	0.95	1005-27	$725.00
D89120829245	D891 ARC DUALLY	POLISHED	20X8.25	8X200	-4.31	-227mm	142.00	51.82 lbs	3000	7.36	1005-30	$725.00
D89120829235	D891 ARC DUALLY	POLISHED	20X8.25	8X200	-3.29	-201mm	142.00	47.63 lbs	3000	7.36	1005-30	$725.00
D891208292	D891 ARC DUALLY	POLISHED	20X8.25	8X200	8.72	104mm	142.00	43.20 lbs	3000	0.95	1005-29	$725.00
D89120829335	D891 ARC DUALLY	POLISHED	20X8.25	8X210	-4.31	-227mm	154.30	50.49 lbs	3000	7.36	1005-30	$725.00
D891208293	D891 ARC DUALLY	POLISHED	20X8.25	8X210	8.72	104mm	154.30	42.80 lbs	3000	0.95	1005-29	$725.00
D89120829345	D891 ARC DUALLY	POLISHED	20X8.25	8X210	-5.06	-246mm	154.30	48.92 lbs	3000	7.88	1005-30	$725.00
D89120829325	D891 ARC DUALLY	POLISHED	20X8.25	8X210	-3.29	-201mm	154.30	46.97 lbs	3000	7.36	1005-30	$725.00

Part#	Model	Finish	Size	Bolt Pattern	Backspace	Offset	Bore	Weight	Load	Lip Size	Cap	MSRP USD
D8672282A9	D867 ARC DUALLY	BLACKOUT	22X8.25	10X225	8.72	104mm	170.10	51.80 lbs	3750	0.98	1004-62BLD	$719.00
D8672282A935	D867 ARC DUALLY	BLACKOUT	22X8.25	10X225	-3.29	-201mm	170.10	51.42 lbs	3750	7.36	1004-63BLD	$719.00
D86722827235	D867 ARC DUALLY	BLACKOUT	22X8.25	8X165.1	-4.31	-227mm	117.00	59.30 lbs	3000	7.36	1005-28BLD	$719.00
D867228272	D867 ARC DUALLY	BLACKOUT	22X8.25	8X165.1	8.72	104mm	117.00	50.50 lbs	3000	1.11	1005-27BLD	$719.00
D86722828D35	D867 ARC DUALLY	BLACKOUT	22X8.25	8X165.1	-4.82	-240mm	121.50	56.76 lbs	3000	7.88	1005-28BLD	$610.00
D86722827225	D867 ARC DUALLY	BLACKOUT	22X8.25	8X165.1	-3.29	-201mm	117.00	54.23 lbs	3000	7.36	1005-28BLD	$719.00
D86722828D	D867 ARC DUALLY	BLACKOUT	22X8.25	8X165.1	8.72	104mm	121.50	50.30 lbs	3000	1.11	1005-27BLD	$610.00
D86722829245	D867 ARC DUALLY	BLACKOUT	22X8.25	8X200	-4.31	-227mm	142.00	57.10 lbs	3000	7.36	1005-30BLD	$610.00
D867228292	D867 ARC DUALLY	BLACKOUT	22X8.25	8X200	8.72	104mm	142.00	49.40 lbs	3000	1.11	1005-29BLD	$610.00
D86722829235	D867 ARC DUALLY	BLACKOUT	22X8.25	8X200	-3.29	-201mm	142.00	52.91 lbs	3000	7.36	1005-30BLD	$610.00
D867228293	D867 ARC DUALLY	BLACKOUT	22X8.25	8X210	8.72	104mm	154.30	49.00 lbs	3000	1.11	1005-29BLD	$610.00
D86722829345	D867 ARC DUALLY	BLACKOUT	22X8.25	8X210	-5.06	-246mm	154.30	55.22 lbs	3000	7.88	1005-30BLD	$719.00
D86722829335	D867 ARC DUALLY	BLACKOUT	22X8.25	8X210	-4.31	-227mm	154.30	55.99 lbs	3000	7.36	1005-30BLD	$610.00
D86722829325	D867 ARC DUALLY	BLACKOUT	22X8.25	8X210	-3.29	-201mm	154.30	52.02 lbs	3000	7.36	1005-30BLD	$719.00
D8682282A9	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	10X225	8.72	104mm	170.10	51.80 lbs	3750	0.98	1004-62GB	$759.00
D8682282A935	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	10X225	-3.29	-201mm	170.10	51.42 lbs	3750	7.36	1004-63GB	$759.00
D86822827235	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X165.1	-4.31	-227mm	117.00	59.30 lbs	3000	7.36	1005-28GB	$759.00
D86822828D	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X165.1	8.72	104mm	121.50	50.30 lbs	3000	1.11	1005-27GB	$675.00
D86822828D35	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X165.1	-4.82	-240mm	121.50	56.76 lbs	3000	7.88	1005-28GB	$675.00
D86822827225	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X165.1	-3.29	-201mm	117.00	54.23 lbs	3000	7.36	1005-28GB	$759.00
D868228272	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X165.1	8.72	104mm	117.00	50.50 lbs	3000	1.11	1005-27GB	$759.00
D86822829235	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X200	-3.29	-201mm	142.00	52.91 lbs	3000	7.36	1005-30GB	$675.00
D868228292	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X200	8.72	104mm	142.00	49.40 lbs	3000	1.11	1005-29GB	$675.00
D86822829245	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X200	-4.31	-227mm	142.00	57.10 lbs	3000	7.36	1005-30GB	$675.00
D868228293	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X210	8.72	104mm	154.30	49.00 lbs	3000	1.11	1005-29GB	$675.00
D86822829335	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X210	-4.31	-227mm	154.30	55.99 lbs	3000	7.36	1005-30GB	$675.00
D86822829325	D868 ARC DUALLY	GLOSS BLACK MILLED	22X8.25	8X210	-3.29	-201mm	154.30	52.02 lbs	3000	7.36	1005-30GB	$759.00
D8912282A9	D891 ARC DUALLY	POLISHED	22X8.25	10X225	8.72	104mm	170.10	51.80 lbs	3750	0.98	1004-62	$850.00
D8912282A935	D891 ARC DUALLY	POLISHED	22X8.25	10X225	-3.29	-201mm	170.10	51.42 lbs	3750	7.36	1004-63	$850.00
D89122828D	D891 ARC DUALLY	POLISHED	22X8.25	8X165.1	8.72	104mm	121.50	50.30 lbs	3000	0.98	1005-27	$800.00
D89122828D35	D891 ARC DUALLY	POLISHED	22X8.25	8X165.1	-4.82	-240mm	121.50	56.20 lbs	3000	7.88	1005-28	$800.00
D89122827235	D891 ARC DUALLY	POLISHED	22X8.25	8X165.1	-4.31	-227mm	117.00	59.30 lbs	3000	7.36	1005-28	$800.00
D89122827225	D891 ARC DUALLY	POLISHED	22X8.25	8X165.1	-3.29	-201mm	117.00	54.23 lbs	3000	7.36	1005-28	$800.00
D89122827245	D891 ARC DUALLY	POLISHED	22X8.25	8X165.1	-5.06	-246mm	117.00	57.30 lbs	3000	7.88	1005-28	$800.00
D89122828D45	D891 ARC DUALLY	POLISHED	22X8.25	8X165.1	-5.81	-265mm	121.50	60.60 lbs	3000	7.88	1005-28	$800.00
D891228217	D891 ARC DUALLY	POLISHED	22X8.25	8X170	8.72	104mm	125.10	50.10 lbs	3000	0.98	1005-27	$800.00
D89122821735	D891 ARC DUALLY	POLISHED	22X8.25	8X170	-3.29	-201mm	125.10	53.79 lbs	3000	7.36	1005-28	$800.00
D89122821745	D891 ARC DUALLY	POLISHED	22X8.25	8X170	-4.31	-227mm	125.10	58.64 lbs	3000	7.36	1005-28	$800.00
D89122829245	D891 ARC DUALLY	POLISHED	22X8.25	8X200	-4.31	-227mm	142.00	57.10 lbs	3000	7.36	1005-30	$800.00
D89122829235	D891 ARC DUALLY	POLISHED	22X8.25	8X200	-3.29	-201mm	142.00	52.91 lbs	3000	7.36	1005-30	$800.00
D891228292	D891 ARC DUALLY	POLISHED	22X8.25	8X200	8.72	104mm	142.00	49.40 lbs	3000	0.98	1005-29	$800.00
D891228293	D891 ARC DUALLY	POLISHED	22X8.25	8X210	8.72	104mm	154.30	49.00 lbs	3000	0.98	1005-29	$800.00
D89122829335	D891 ARC DUALLY	POLISHED	22X8.25	8X210	-4.31	-227mm	154.30	55.99 lbs	3000	7.36	1005-30	$800.00
D89122829325	D891 ARC DUALLY	POLISHED	22X8.25	8X210	-3.29	-201mm	154.30	52.02 lbs	3000	7.36	1005-30	$800.00
D89122829345	D891 ARC DUALLY	POLISHED	22X8.25	8X210	-5.06	-246mm	154.30	54.22 lbs	3000	7.88	1005-30	$800.00
